UNV 5MP HD Intelligent LightHunter IR VF Dome Network Camera (Kuwait Only) | UNV-IPC3235SB-ADZK-I0

UNV 5MP HD Intelligent LightHunter IR VF Dome Network Camera (Kuwait Only) | UNV-IPC3235SB-ADZK-I0

Introducing the UNV 5MP HD Intelligent LightHunter IR VF Dome Network Camera, exclusively designed for Kuwait - model UNV-IPC3235SB-ADZK-I0. This advanced surveillance solution is meticulously crafted to provide exceptional security features and cutting-edge technology. With a high-resolution 5-megapixel sensor, the UNV-IPC3235SB-ADZK-I0 ensures clear and detailed visuals, optimizing identification and monitoring in various scenarios.

Features

• High-quality image with 5MP, 1/2.7"CMOS sensor
• 5MP (2880*1620)@ 30/25fps; 4MP (2560*1440)@ 30/25fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps
• Ultra 265, H.265, H.264, MJPEG
• Intelligent perimeter protection includes cross-line intrusion, enter area, leave area detection
• Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds, lights, etc., accurately focusing on human, motor vehicle, and non-motor vehicle
• LightHunter technology ensures ultra-high image quality in a low-illumination environment
• 120dB true WDR technology enables a clear image in a strong light scene
• Support 9:16 Corridor Mode
• Built-in Mic
• Alarm:1 in/1 out, Audio: 1 in/1 out
• Smart IR, up to 40m (131ft) IR distance
• Supports 256 G Micro SD card
• IK10 vandal resistant
• IP67 protection
• Support PoE power supply

Technical Specifications

Camera

• Sensor: 1/2.7", 5.0 megapixel, progressive scan, CMOS
• Lens: 2.7 ~ 13.5mm, AF automatic focusing and motorized zoom lens
• DORI Distance
• Lens (mm): 2.7~13.5
• Detect (m): 60.8~303.8
• Observe (m): 24.3~121.5
• Recognize (m): 12.2~60.8
• Identify (m): 6.1~30.4
• Angle of View (H): 106.25°~ 30.42°
• Angle of View (V): 56.36°~ 17.22°
• Angle of View (D): 110.34°~34.18°
• Adjustment angle
• Pan: 0° ~ 355°
• Tilt: 0° ~ 80°
• Rotate: 0° ~ 355°
• Shutter: Auto/Manual, 1/3 ~ 1/100000s
• Minimum Illumination: Colour:0.002 Lux (F1.2, AGC ON) 0Lux with IR
• Day/Night: IR-cut filter with auto switch (ICR)
• Digital Noise Reduction: 2D/3D DNR
• S/N: >56dB
• IR Range: Up to 40m (131ft) IR range
• Wavelength: 850nm
• IR On/Off Control: Auto/Manual
• Defog: Digital Defog
• WDR: 120dB

Video

• Video Compression: Ultra 265, H.265, H.264, MJPEG
• H.264 Code Profile: Baseline profile, Main Profile, High profile
• Frame Rate
• Main Stream: 5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps;
• Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
• Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
• Video Bit Rate: 128 Kbps~16 Mbps
• U-code: Support
• OSD: Up to 8 OSDs
• Privacy Mask: Up to 4 areas
• ROI: Up to 8 areas
• Motion Detection: Up to 4 areas


• White Balance: Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
• Smart IR: Supported
• Flip: Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
• Dewarping: N/A
• HLC: Supported
• BLC: Supported

Audio

• Audio Compression: G.711
• Two-way Audio: Supported
• Suppression: Supported
• Sampling Rate: 8KHZ

Storage

• Edge Storage: Micro SD, up to 256GB
• Network Storage: ANR

Intelligent

• Smart intrusion prevention: Cross line, intrusion, enter area, leave area detection

Events

• Basic Detection: Motion detection, tampering alarm, audio detection Loitering, and people gathering
• General Function: Watermark, IP address filtering, tampering alarm, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication.

Network

• Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
• Compatible Integration: ONVIF (Profile S, Profile G, Profile T), API
• Client: EZStation/EZView/EZLive
• Web Browser
• Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
• Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+, Safari 11+

Interface

• Audio I/O
• Input: impedance 35kΩ; amplitude 2V [p-p]
• Output: impedance 600Ω; amplitude 2V [p-p]
• Alarm I/O: 1/1
• RS485: N/A
• Built-in Mic: Supported
• Network: 1 RJ45 10M/100M Base-TX Ethernet

Certifications

• CE: EN 60950-1
• UL: UL60950-1
• FCC: FCC Part 15

General

• Power: DC 12V±25%, PoE (IEEE 802.3af)
• Power consumption: Max 7.0 W
• Power Interface: Ø 5.5mm coaxial power plug
• Dimensions (Ø x H): Φ148.0 x 111.4mm (Ø5.8” x 4.4”)
• Weight: 0.97kg (2.12lb)
• Material: Metal + Plastic
• Working Environment: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
• Storage Environment: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
• Surge Protection: 6KV
• Reset Button: Supported
• Ingress Protection: IP67

Product Literature

• UNV IPC3235SB-ADZK-I0 Data Sheet
• UNV IPC3200 Series-Network Fixed Dome Cameras Quick Guide-V1.01
• UNV Camera Installation Guide V1.00

• UNV Network Cameras User Manual V2.08
