FAAC 400 CBACR Rapid Hydraulic Swing Gate Operator (Basic Single Kit)

FAAC 400 CBACR Rapid Hydraulic Swing Gate Operator (Basic Single Kit)

The FAAC Model 400 Swing Gate Operator consists of an electric pump and a hydraulic piston that transmits drive to the gate leaf.

Models with hydraulic locking do not require the installation of electric locks, as they provide mechanical locking of the leaf when the motor is not operating. Models without hydraulic locking require the installation of electric locks to ensure that the leaf is mechanically locked.

The 400 Operators were designed and built to automate swing leaf gates. Do not use it for any other purpose.

Includes

• 1 - Operator 400 CBAC
• 1 - 455D with 18 x 16 in. metal enclosure - 455D115.1 (115V models) or 455D220.1 (220V models)
• 1 - Receiver 433 RC Plug-In - 787856
• 2 - 4-channel transmitter XT4 433 RC - 787453
• 1 - Pair of XP 30 photobeam photocells - 785105
• 2 - XP 30 adapters for conduit connection - 401064

Manufacturer's Warranty Period

• 3 years

Notes

• Mounting dimensions, wind factor, and gate design will affect the performance specification
• Use frequency is measured at an ambient temperature of 72 °F (20 °C). Temperature variation will affect it
• An electric or magnetic lock is recommended for any gate longer than 12 ft (3.6m)
• Positive gate stops, which limit gate travel, are required in the open and closed positions

Note: This product has an updated part number.

• New Part Number: 1042071_5 (Old Part Number: 1042071.5)
• New Part Number: 10420712_5 (Old Part Number: 10420712.5)
• New Part Number: 1042071277_5 (Old Part Number: 1042071277.5)
• New Part Number: 104207177_5 (Old Part Number: 104207177.5)
